CLA-1886621 Claas Lexion 405, 410, 415, 420. 430, 440, 450, 460 combine harvester repair manual
CLA-1886621 Claas Lexion 405, 410, 415, 420. 430, 440, 450, 460 combine harvester repair manual
English

Claas Lexion 405, 410, 415, 420. 430, 440, 450, 460 combine harvester repair manual

CLA-1886621
$34.90
No tax

Format: PDF

Pages: 988

File size: 36,42 MB

PDF document is available for instant download after purchase at any time. Can be downloaded and viewed on any device. Download free preview PDF file using link in Attachments TAB

CLA-1886621-preview.pdf - 1.51MB
Log in to access your free preview PDF

Try Before You Buy
Sign in or create a quick account in seconds to download a free preview PDF file, where you find "Bookmarks" tab to see the complete table of contents. Review the manual's layout, detail, and quality to ensure it’s exactly what you need.

Create an account and join to our cumulative discounts program. Spend at least $29.9 and get 10.00% discount.
Rating:
(0)


Table of Contents for CLA-1886621 manual

  • Contents
  • General information
    • General
    • Safety Rules
    • General repair information
    • Tightening torques
    • Specifications
    • Sectional view of machine
    • Drive diagram
  • Operator's platform
    • Air conditioner
    • Steering
    • Parking brake
    • Foot brake
    • Engine electric system
  • Threshing mechanism
    • Feed rake conveyor
    • Threshing concave
    • Accelerator
    • Threshing drum
    • Impeller
  • Cleaning unit
    • Under-walker return floor
    • Straw walker
    • Intensive separation system
    • Sieve pan
    • Preparation floor
    • 3-D sieve pan control system
    • Rocker arm drive
    • Cleaning fan
  • Grain delivery
    • Returns elevator
    • Grain elevator
    • Grain tank unloading
  • Straw discharge
    • Straw chopper
    • Chaff spreader
  • Drives
    • Drive belts
    • Left-hand drive belts
    • Right-hand drive belts
    • Cutterbar drive
    • Left-hand threshing mechanism drive
    • Right-hand threshing mechanism drive
    • Threshing drum reduction gearbox
    • Threshing mechanism intermediate drive
    • Grain tank unloading drive
    • Chopper drive
    • Straw spreader drive
    • Sieve pan drive
    • Fan drive
    • Engine output
    • Rotary screen drive
    • Final drives
    • Manual gearbox
    • Brake
    • Steering axle
  • Machine body
    • Rotary screen
    • Drive axle
  • Hydraulic system
    • Oil cooler
    • Maintenance
    • Hydraulic pumps
    • Hydrostatic fixed displacement motors
    • Hydraulic cylinders – High-pressure hydraulic circuit
    • Hydraulic cylinders for low-pressure hydraulics
    • Hydraulic cylinder – Steering hydraulics
    • Valve combinations
  • Engine
    • Cooling system
    • Fuel system
    • Engine
  • Index
    • Index
Document type
Repair manual
Language
English
Machinery type
grain combine
CLA-1886621-preview.pdf - 1.51MB
