Claas Lexion 600 - 510 combine harvester technical systems manual

Table of Contents for CLA-2936765 manual

• LEXION 600 - 510 - From serial number: 589 00018, 586 00918, 585 00358, 584 02256, 583 00868 Technical Systems - Electric System
• Contents
• Central terminal compartment
  • Fuses:
  • Relays:
  • Interconnections within central terminal compartment
  • Connecting cable (module PCB – base PCB)
• Pin assignment in modules
  • Module A6 • Automatic air conditioner
  • Module A7 • Cab fan speed controller
  • Module A8 • AUTOCONTOUR (CAC)
  • Module A9 • AUTOPILOT (ATP)
  • Module A10 • Fieldwork computer (BIF/CAB)
  • Module A12 • Speed monitor (DZW)
  • Module A13 • Performance monitor (DKG)
  • Module A15 • Electronic engine control module CATERPILLAR (CAT C13, C12, C10, C9, 3126B)
  • Module A17 • Engine adaptation module ADM DAIMLER-CHRYSLER (DC)
  • Module A21 • Yield meter
  • Module A25 • Sieve adjustment
  • Module A27 • VARIO
  • Module A28 • Uni-spreader (VGS)
  • Module A30 • Terminal Cebis
  • Module A34 • Grain tank
  • Module A37 • Electro-hydraulic gearshift (EHS) • 3-speed manual gearbox
  • Module A38 • Rotor (RIO)
  • Module A39 • Cruise pilot
  • Modul A42 • Modul MONTANA GEN II - X1 (42pol)
  • Module A46 • Deflector adjustment (RIO)
  • Module A49 • Ground drive (EFA)
  • Module A51 • Radial spreader
  • Module A65 • GPS pilot terminal
  • Module A66 • GPS pilot module (GPB)
  • Module A79 • Rear driving axle module (RAD)
  • Module A83 • 4-Trac enable module
• Circuit diagrams 01a - 50a
  • 01a Main power supply, diesel engine electric starting motor
  • 02a Starting the diesel engine, diesel engine electric starting motor
  • 02b Starting the diesel engine, diesel engine electric starting motor
  • 02c Starting the diesel engine, diesel engine electric starting motor
  • 02d Starting the diesel engine, diesel engine electric starting motor - DC 502 LA
  • 03a Diesel engine cut-off system
  • 04a Road travel activation, master valve (not with electro-hydraulic ground drive)
  • 04b Road travel activation, master valve - with electro-hydraulic ground drive (EFA)
  • 05a Terminal, keyboard, rotary switch, printer (not with electro-hydraulic ground drive)
  • 05b Terminal, keyboard, rotary switch, printer - with electro-hydraulic ground drive (EFA)
  • 06a CAN bus, module power supply, for diesel engine CATERPILLAR - C13, C12, C10, C9, 3126B
  • 06b CAN bus, module power supply, for diesel engine CATERPILLAR - C6.6
  • 06c CAN bus, module power supply, for diesel engine Daimler - Chrysler DC 502 LA
  • 07a Threshing mechanism circuit
  • 08a Concave adjustment / Threshing drum variable-speed drive
  • 09a Rotor flap adjustment / Rotor variable-speed drive
  • 10a Fan variable-speed drive
  • 11a Sieve adjustment
  • 12a Deflector adjustment
  • 13a Straw and chaff spreader, uni-spreader
  • 13b Straw and chaff spreader, radial spreader
  • 14a Swinging the grain tank unloading tube
  • 15a Grain tank unloading / Grain tank unloading aid
  • 16a Rape cutting knife circuit
  • 17a Front attachment drive, reverser drive, front attachment quick stop
  • 18a Front attachment variable-speed drive
  • 19a Straw chopper - Standard chopper for LEXION 570 - 510
  • 19b Straw chopper - Radial spreader for LEXION 600 - 570
  • 20a Front attachment raise/lower, cross levelling
  • 21a Reel adjustment - Standard cutterbar, folding cutterbar, MaxFlex soybean header
  • 21b Reel adjustment - VARIO cutterbar
  • 21c Maize picker Conspeed - Folding the maize picker, snapping plate adjustment, down maize augers
  • 21d Rake-up – Drive, rake-up crop guard adjustment
  • 22a Reel variable-speed drive
  • 23a Cutting table adjustment (Vario), folding the cutterbar
  • 23b Cutting table adjustment - MaxFlex
  • 24a AUTOCONTOUR (CAC)
  • 25a Speed monitor
  • 26a Machine monitor (not with electro-hydraulic ground drive)
  • 26b Machine monitor - with electro-hydraulic ground drive (EFA)
  • 27a Yield meter / Grainmeter
  • 28a AUTOPILOT - Laser system
  • 28b AUTOPILOT - Feeler system
  • 28c AUTOPILOT – GPS-controlled steering
  • 29a Performance monitor
  • 30a Open / close grain tank (electric), grain tank full signal, warning beacon
  • 30b Open / close grain tank (hydraulic), grain tank full signal, warning beacon
  • 31a Front attachment dampening
  • 32a All-wheel drive - overdrive, fuel tank (not with electro-hydraulic ground drive)
  • 32b All-wheel drive - overdrive, fuel tank
  • 32cAll-wheel drive - rear exit drive,fuel tank
  • 33a Cutterbar spring lock (only when front attachment cylinder is equipped with a spring)
  • 36a Indicator system (Europe)
  • 36b Indicator system (USA)
  • 37a Windscreen wiper, windscreen washer
  • 38a Compressor-type air conditioner
  • 38b Automatic air conditioner
  • 39a Cab comfort equipment - operator's seat
  • 40a Additional sockets, fuse tester
  • 42a Ground drive and brake control - with electro-hydraulic ground drive (EFA)
  • 43a Electro-hydraulic ground drive (EFA), „CRUISE PILOT"
  • 44a Electro-hydraulic gearshift (EHS) - 3-speed manual gearbox
  • 44b Electro-hydraulic gearshift (EHS) - 2-speed manual gearbox (not for LEXION Montana*)
  • 45a Main lighting circuit, taillight, position light
  • 46a Dipped headlights, full beam, dipped headlights changeover switch
  • 47a Work lights I
  • 48a Work lights II
  • 49a Sieve, grain tank and returns lighting, reversing horn, brake light (not with electro-hydraulic ground drive)
  • 49b Sieve, grain tank and returns lighting, reversing horn, brake light - with electro-hydraulic ground drive (EFA)
  • 50a Instrument lighting, broadcast receiver, mirror adjustment
• Component grid
• Index
  • A–C
  • D–F
  • G–L
  • M–R
  • S–Y
• 00 0294 059.4
