Claas Dominator 48-68 combine harvester technical systems manual

Table of Contents for CLA-2998561 manual

• Technical Systems - Hydraulic System DOMINATOR 48 - 68, DO 48 from Serial No. 15403117, DO 68 from Serial No. 15608462
• 1 Overall hydraulic system
  • 1.1 Hydraulic system - General
  • 1.2 Overall hydraulic system circuit diagram
  • 1.2.1 Overall hydraulic system circuit diagram - without straw collector
  • 1.2.2 Overall hydraulic system circuit diagram - with straw collector
• 2 Steering hydraulics / 3-D sieve pan control system
  • 2.1 Steering hydraulics circuit diagram without AUTOPILOT
  • 2.2 Steering hydraulics circuit diagram with AUTOPILOT
  • 2.3 Steering valve unit
  • 2.4 Function of steering
  • 2.5 Checking the steering
  • 2.6 AUTOPILOT solenoid valve
  • 2.7 Checking the AUTOPILOT system
  • 2.8 3-D sieve pan control system
• 3 Working hydraulics
  • 3.1 Working hydraulics circuit diagram
  • 3.2 Pressure relief valve
  • 3.3 Swinging the grain tank unloading tube
  • 3.4 Lock-up valve unit
  • 3.5 Flow divider (option) - for horizontal reel adjustment and/or straw collector
  • 3.6 Automatic cutting height control (option)
  • 3.7 Horizontal reel adjustment
  • 3.8 Raise / lower front attachment, variator variable-speed drive, vertical reel adjustment, threshing drum variable-speed drive
  • 3.9 Variator foot valve
  • 3.10 Straw collector
• Position of components
• Component grid
• Index
• 0299 856.1
