Case IH Farmall 110N, 100N, 90N, 80N tractor pdf operator's manual

Name: Case IH Farmall 110N, 100N, 90N, 80N tractor pdf operator's manual
Brand: Case IH
SKU: CASE-48042335
Price: 16.9 USD
Availability: InStock

Reference CASE-48042335

$16.90

No tax

Format: PDF

Pages: 392

File size: 16.86 MB

Language: English

Models: Farmall 110N, Farmall 100N, Farmall 90N, Farmall 80N

CASE-48042335-EN-preview.pdf - 908.5KB
Log in to access your free preview PDF

Try Before You Buy
Sign in or create a quick account in seconds to download a free preview PDF file, where you find "Bookmarks" tab to see the complete table of contents. Review the manual's layout, detail, and quality to ensure it’s exactly what you need.

Create an account and join to our cumulative discounts program. Spend at least $29.9 and get 10.00% discount.

Rating:

(0)

Table of Contents for CASE-48042335-EN manual

OPERATOR'S MANUAL
Contents
1 GENERAL INFORMATION
- Note to the Owner
- Intended use
- Electro-Magnetic Compatibility (EMC)
- Manual scope and required training level
- Metric and imperial units abbreviations
- Identification plates
- Operator's manual storage
- Machine orientation
- Exhaust Gas Recirculation (EGR) system
2 SAFETY INFORMATION
- Safety rules and signal word definitions
- Safety rules General information
- Safety rules – Maintenance
- Safety rules Wheels and tires
- Safety rules – Explosions and fires
- Safety rules Fire extinguisher
- Proposition 65
- Safety rules – Battery
- Safety rules – Operator presence system
- Safety rules Power Take-Off (PTO)
- Safety rules Reflectors and warning lights
- Safety rules Seat belts
- Safety rules Operator protective structure
- Safety rules Category 2 cabin (standard)
- Safety rules Category 4 cabin (if equipped)
- Safety rules HVAC system
- Safety rules Personal Protective Equipment (PPE)
- Safety rules "Do not use" sign
- Safety rules Hazardous chemicals
- Safety rules Near utilities
- Safety rules In the event of electrical storms
- Safety rules – Mounting and dismounting the machine
- Safety rules Lifting and overhead loads
- Ecology and the environment
- Noise level
- Vibration levels
- Safety signs
- Towing the tractor for recovery
- Tractor jacking points
- Burn prevention
- Emergency exit
3 CONTROLS AND INSTRUMENTS
- Mounting and dismounting
- Getting to know the internal parts of the cab
- Mechanical suspension seat
- Air seat
- Safety belt
- Instrument cluster
- Front controls
- Left-hand side controls
- Right hand side controls
- Overhead controls
- Exterior controls
- Analog Digital Instrument Cluster (ADIC) programming
- Ground speed calibration
- Calibrating tool width
- Programming maintenance work
- Activating/deactivating buzzer
- Setting units of measurement
- Regenerating the diesel particulate filter (DPF) automatically/ manually
- Resetting the oil change counter
- Viewing error codes
4 OPERATING INSTRUCTIONS
- Basic operating safety rules
- Refueling
- Starting engine
- Stopping the engine
- Electronic battery isolator Overview
- Machine movement start-up
- Idle speed management
- Mechanical transmission with mechanical shuttle (16x16)
- Mechanical transmission and creeper (28x16)
- Transmission with Power Shuttle (16x16)
- Hi-Lo transmission (32x16)
- Hi-Lo transmission and creeper (44x16)
5 TRANSPORT OPERATIONS
- Transporting the machine
- Towing the tractor
6 WORKING OPERATIONS
- Manual Accelerator
- Foot accelerator
- Constant engine RPM
- Clutch pedal
- Brake pedals Safety rules
- Service brakes
- Parking brake
- Park lock
- Four-wheel drive
- Differential lock
- Air-conditioning system
- Air filtration system of Category 4 cab Operating
- Remote control valves Safety rules
- Rear remotes valves Overview
- Mechanically controlled rear remotes valves
- Electronically controlled rear remotes valves
- Mid mount valves Models with 64 L/min (16.91 US gpm) pump
- Mid mount valves Models with 80 L/min (21.13 US gpm) pump
- Rear Power Take-Off (PTO) Safety rules
- Rear Power Take-Off (PTO) Overview
- Power Take-Off Speeds
- Rear Power Take-Off (PTO) How it works
- Front Power Take-Off (PTO) Safety rules
- Front Power Take-Off (PTO) Operating
- Rear hydraulic lift Safety rules
- Rear hydraulic lift Overview
- Rear hydraulic lift with mechanical control Models with cab
- Rear hydraulic lift with mechanical control Models without cab
- Electronically controlled rear hydraulic lift
- Rear three-point hitch Safety rules
- Rear three-point hitch Operating
- Front hitch Safety rules
- Front hitch Operating
- Drawbar Safety rules
- Towbar
- Wheels General specification
- Tires size
- Track adjustment
- Front tracks diagram
- Rear tracks diagram
- Metal ballast
- Liquid ballast
- Power sockets
- Rotating beacon
7 MAINTENANCE
- General safety before you service
- Introduction
- Body maintenance
- Exhaust Gas Recirculation (EGR) exhaust treatment Basic instructions Resetting the oil life monitoring system
- Fuel injection system General specification Biodiesel fuels
- General specification Diesel fuel
- Organic Acid Technology (OAT) coolant
- Capacities
- Consumables
- Hood Basic instructions
- Removing the engine side shields
- Maintenance chart
- Expansion tank Level make up
- Windshield washer fluid reservoir Level make up
- Road lamps – Adjust
- Clutch pedal Adjust
- Parking brake Adjust
- Oil cooler Drive line Cleaning
- Radiator and intercooler Cleaning
- Tires - Pressure check and general conditions
- Air cleaner Cleaning
- Fuel filters Cleaning glass first stage fuel filter
- Cab climate control Check
- Engine lubrication system Replace oil
- Cab air filter category 2 Check
- Cab air filter category 4 Check
- Cab air filter category 4 Replace
- Engine air filter Cleaning
- Fuel filters Drain fluid
- Brake fluid Level make up
- Expansion tank Check Coolant Level
- Engine lubrication system Check
- Engine cooling system Check expansion tank fluid level
- Brake fluid reservoir Check
- Engine air cleaner check
- Windshield washer fluid reservoir Check
- Oil cooler Transmission Check
- Radiator and intercooler Control
- Fuel filters Check glass pre filter
- Brake pedals Check coupling pin
- Maintenance Tighten
- Maintenance Check
- Maintenance Replace
- Maintenance Cleaning
- Maintenance Test
- Maintenance Grease
- 2WD steering cylinder
- 2WD front axle pivot
- 2WD right and left-hand stub axle
- 4WD front axle pivot
- Hydraulic lift and linkage Greasing
- Front three-point hitch Greasing
- Oil cooler Transmission Check
- Radiator and intercooler Control
- Oil cooler Drive line Cleaning
- Oil cooler and lines Check drives
- Radiator and intercooler Cleaning
- Air conditioner condenser Cleaning
- Cab air filter category 2 Clean
- Cab air recirculation filter Cleaning
- Alternator drive belt Check
- Air conditioning compressor belt Check
- Hydraulic oil filter Replace
- Transmission oil filter Replace
- Drive line lubrication Check the oil level
- Engine air filter Cleaning
- Brake system Control
- 4WD front axle housing Check the oil level
- 4WD front axle final drives Oil level check
- 4WD front axle steering knuckles Greasing
- Engine lubrication system Change fluid Change oil and filter (Models without a cab)
- Engine lubrication system Change fluid Change oil and filter (Models with a cab)
- Fuel filters Replace
- Fuel filters Cleaning
- Clutch pedal Control
- Air intake lines Check
- Front Power Take-Off (PTO) Check
- Front Power Take-Off (PTO) Check Oil breather
- Front and rear wheel nuts Check tightening torque
- Cab air filter category 2 Replace
- Cab air recirculation filter Replace
- Engine air filters Replace
- Fuel reservoir Drain
- Rear wheel hub Greasing
- 4WD front axle housing With brake
- 4WD front axle housing Without brake
- 4WD front axle final drives Change oil
- Mechanical transmission hydraulic components Change fluid replacement
- Alternator drive belt Replace
- Air conditioning compressor belt Replace
- Front Power Take-Off (PTO) Change oil
- Engine cooling system Change fluid (conventional liquid)
- Receiver-dryer Replace
- Engine cooling system Change fluid (OAT fluid)
- Diesel Particulate Filters (DPF) Replace
- Brake fluid reservoir Change fluid
- Road lamps – Adjust
- Road lamps replacement
- Battery access and service
- Battery cut-off switch
- Fuse and relay box Overview
- Main fusebox
- Cab fuse box
- Maxi fuse box
- Tractor storage
- two-speed Powershift transmission Calibrate
- Electronic lift calibration
8 TROUBLESHOOTING
- TROUBLESHOOTING ENGINE
- Electrical system Troubleshooting ELECTRICAL SYSTEM
- Hydraulic systems Troubleshooting HYDRAULIC SYSTEM
- Couplers Troubleshooting
- Rear three-point hitch Troubleshooting
- Hydraulic service brakes Troubleshooting
- Cab climate control Troubleshooting
- Alarms
- Display warnings overview
- SYMPTOM(S)
9 SPECIFICATIONS
- Dimensions and weights
- Maximum permitted loads on front and rear axle
- Maximum permitted loads on drawbar
- Additional equipment attachment points
- Speed table for 16x16 gearbox
- Speed table for 28x16 gearbox
- Speed table for 32x16 gearbox
- Speed table 44x16 gearbox
- Capacities
- Consumables
- Technical data
10 ACCESSORIES
- Tool box
- Radio
Index

Document type: Operator's manual
Language: English
Machinery type: tractor
