Case Magnum 250, 280, 310, 340, 380 PIN ZHRF04001- tractor pdf operator's manual (48158467)
English

Case Magnum 250, 280, 310, 340, 380 PIN ZHRF04001- tractor pdf operator's manual (48158467)

CASE-48158467-OM-EN
$19.90
No tax

Item Number: 48158467

Models: Magnum 250, Magnum 280, Magnum 310, Magnum 340, Magnum 380, Magnum 310 Rowtrac, Magnum 340 Rowtrac, Magnum 380 Rowtrac Tractors

Format: PDF

Type: Operator's manual

Pages: 764

File size: 46.67 MB

Language: English

Date: September 2017

Issue: 1st edition

P.I.N.: PIN ZHRF04001 and above

CASE-48158467-OM-EN-preview.pdf - 2.59MB
Log in to access your free preview PDF

Try Before You Buy
Sign in or create a quick account in seconds to download a free preview PDF file, where you find "Bookmarks" tab to see the complete table of contents. Review the manual's layout, detail, and quality to ensure it’s exactly what you need.

Create an account and join to our cumulative discounts program. Spend at least $29.9 and get 10.00% discount.
Rating:
(0)


Table of Contents for CASE-48158467-OM-EN manual

  • GENERAL INFORMATION
    • Note to the owner
    • Engine tampering
    • Tractor intended use
    • Electro-magnetic compatibility (EMC)
    • ISOBUS certification
    • Product identification
    • Manual storage
    • Machine orientation
    • Component identification
    • Selective Catalytic Reduction (SCR) system
  • SAFETY INFORMATION
    • Safety rules and signal word definitions
    • Safety rules - General
    • Safety rules - General maintenance safety
    • Safety rules - Wheels and tires
    • Safety rules - Driving on public roads and general transportation safety
    • Safety rules - Fire and explosion prevention
    • Safety rules - General battery safety
    • Safety rules - Hydraulic system safety
    • Safety rules - Instructional seat safety
    • Safety rules - Operator presence system
    • Safety rules - Power Take-Off (PTO)
    • Safety rules - Reflectors and warning lights
    • Safety rules - Seat belts
    • Safety rules - Roll Over Protective Structure (ROPS)
    • Safety rules - Cab protection
    • Safety rules - Air conditioning system
    • Safety rules - Personal Protective Equipment (PPE)
    • Safety rules - Do Not Operate tag
    • Safety rules - Hazardous chemicals
    • Safety rules - Utility safety
    • Safety rules - Electrical storm safety
    • Safety rules - Mounting and dismounting
    • Safety rules - Working at heights
    • Safety rules - Lifting and overhead loads
    • Safety rules - Implements, tools and trailers
    • Safety rules - Roll over and tip over
    • Proposition 65
    • Ecology and the environment
    • Safety signs
    • Selective Catalytic Reduction (SCR) exhaust treatment - Safety signs
    • Informational signs
  • CONTROLS AND INSTRUMENTS
    • ACCESS TO OPERATOR'S PLATFORM
    • OPERATOR'S SEAT
    • INSTRUCTOR'S SEAT
    • FORWARD CONTROLS
    • LEFT-HAND SIDE CONTROLS
    • RIGHT-HAND SIDE CONTROLS
    • REARWARD CONTROLS
    • OVERHEAD CONTROLS
    • EXTERIOR CONTROLS
    • INSTRUMENT CLUSTER
  • OPERATING INSTRUCTIONS
    • COMMISSIONING THE UNIT
    • STARTING THE UNIT
    • STOPPING THE UNIT
    • MOVING THE UNIT
  • NO TITLE
    • NO TITLE
  • NO TITLE
    • NO TITLE
  • NO TITLE
    • NO TITLE
    • PARKING THE UNIT
  • TRANSPORT OPERATIONS
    • ROAD TRANSPORT
    • SHIPPING TRANSPORT
    • RECOVERY TRANSPORT
  • WORKING OPERATIONS
    • GENERAL INFORMATION
    • REAR POWER TAKE-OFF (PTO)
    • FRONT POWER TAKE-OFF (PTO)
    • REAR HITCH
    • FRONT HITCH
    • DRAWBARS AND TOWING ATTACHMENTS
    • TRAILER BRAKING SYSTEMS
    • AUXILIARY CONNECTIONS
    • HYDRAULIC REMOTE CONTROL VALVES
    • BALLASTING THE TRACTOR
    • MECHANICAL FRONT DRIVE (MFD) AXLES
    • REAR AXLE
    • REAR TRACKS
  • MAINTENANCE
    • GENERAL INFORMATION
    • Maintenance planning
    • At warning message display
    • First 10 to 50 hours
    • Every 10 hours or daily
    • Every 50 hours or weekly
    • First 100 hours
    • Every 100 hours
    • Every 200 hours
    • Every 300 hours
    • Every 400 hours
    • Every 600 hours
    • Every 1000 hours or annually
    • Every 1200 hours or annually
    • Every 1500 hours
    • Every 3000 hours
    • Every 3600 hours
    • Every 4000 hours or every four years
    • As required
    • Fuse and relay locations
    • STORAGE
    • ELECTRICAL SYSTEM
  • TROUBLESHOOTING
    • ALARM(S)
    • SYMPTOM(S)
  • SPECIFICATIONS
    • Engine specifications
    • Power train specifications
    • Operating speeds - Wheeled tractors
    • Operating speeds - Rowtrac™ tractors
    • Maximum angle (tilt) of operation
    • Vehicle dimensions and shipping weight - Wheeled tractors
    • Vehicle dimensions and shipping weight - Rowtrac™ tractors
    • Maximum operating weight
  • ACCESSORIES
    • Farming system displays
    • Rear view mirrors
    • Chemical tank mounting
    • Loader connection and operation
    • General accessories
