Massey Ferguson 415, 425, 435, 440, 445, 460, 465, 475 tractor pdf workshop service manual

Table of Contents for MF-400-01-WSM-EN manual

• CONTENTS
• Introduction
  • 1 - Presentation
  • 2 - Safety
  • 3 - Correct workshop techniques
  • 4 - Basics of measurement
  • 5 - General table of recommended torques for bolts
  • 6 - Technical units
  • 7 - Loctite products for the workshop
  • 8 - AGCO environmental policy
  • 9 - Compulsory recycling of batteries
• Splitting the tractor
  • 1 - Introduction
  • 2 - Splitting the tractor between the engine and the front axle
  • 3 - Splitting the tractor between the engine and the gearbox
  • 4 - Splitting the tractor between the gearbox and the rear axle
  • 5 - ROPS + canopy + fender assy removal
  • 6 - Front hood sheet metal removal
• 2 WD Front axle
  • 1 - Introduction
  • 2 - Wheel alignment
  • 3 - Front wheel hubs
  • 4 - Outer arm and spindle shaft
  • 5 - Front axle central beam
  • 6 - MF 415 tractor axle
• 4WD Front Axles Carraro 20.14, 20.18 and 20.21
  • 1 - Introduction
  • 2 - Final drive
  • 3 - Final drive pivoting
  • 4 - Half-shaft spiders
  • 5 - Bushingings and retainers of trumpets and pivots
  • 6 - Pinion and differential assy
  • 7 - Driving box and front bearing shell
  • 8 - Steering cylinder
  • 9 - Tightening torques
• 4WD Front Axles ZF / APL 335, 345 e 350
  • 1 - Introduction
  • 2 - Final drives
  • 3 - Differential, pinion and trumpets
  • 4 - Secondary drive box, brackets and bearings
  • 5 - Mechanical-type side drive box
  • 6 - Spacer and four-wheel central drive box
  • 7 - Steering hydraulic cylinder
  • 8 - Adjustment specifications
• Perkins Engines
  • 1 - Adjustment of valve tip clearance
  • 2 - Nozzles inspection
  • 3 - Adjustment of the injection point
  • 4 - Compression test for cylinders
  • 5 - Basic technical specifications
  • 6 - Workshop specifications
• Clutch
  • 1 - Types of clutches used on MF 400 Series tractors
  • 2 - Clutches and flywheels fitted on the MF 400 Series tractors
  • 3 - General information and recommendations about clutches
  • 4 - Dual-stage and split-torque clutch: components identification
  • 5 - Clutch removal and disassembly
  • 6 - Inspection and refitment of the components
  • 7 - Clutch reassembly (dual-stage and split-torque)
  • 8 - Engine flywheel
  • 9 - Clutch refitment and final adjustments
  • 10 - Clutch troubleshooting
• 8x2 Speeds Gearbox sliding gears type
  • 1 - Introduction
  • 2 - Lever cover and gear shift levers
  • 3 - Shafts, selector rails and forks
  • 4 - Slow/Fast ranges assy
  • 5 - Clutch release mechanism
  • 6 - Brake pedal cross-shaft
  • 7 - Gearbox inner assy disassembly and inspection
  • 8 - Gearbox inner assy reassembly
  • 9 - Creeper
• Eaton Constant Mesh 12x4 Speeds Gearbox
  • 1 - Introduction
  • 2 - Gearbox removal and adaptation to service support
  • 3 - Speed selector system - foot step type tractors
  • 4 - Gear selector system - cab tractors
  • 5 - Clutch mechanisms
  • 6 - Slow and Fast speed range assy
  • 7 - Front retainer flange and input shafts
  • 8 - Main shaft (or output shaft)
  • 9 - PTO output shaft and layshaft (lower shaft)
  • 10 - Reverse gear assy
  • 11 - Components inspection and failure diagnosis
  • 12 - Creeper
• Eaton Synchromesh 12x4 Speeds gearbox
  • 1 - Introduction
  • 2 - Gearbox removal and adaptation to service support
  • 3 - Clutch mechanism
  • 4 - Gear selector system: shift lever shafts and forks
  • 5 - Fast & Slow assembly
  • 6 - Front flange and input shafts
  • 7 - Main shaft (or output shaft)
  • 8 - PTO output shaft and layshaft (lower)
  • 9 - Reverse gear assy
  • 10 - Synchromesh sets
  • 11 - Components inspection and failure diagnosis
• Module H: Rear Axle
  • 1 - Description and operation
  • 2 - Final drives
  • 3 - Trumpets
  • 4 - Brakes
  • 5 - Differential
  • 6 - Pinion
  • 7 - Adjustments and reinstallation of the ring gear and pinion assembly
  • 8 - Half shaft without final drive - MF 415 tractors
  • 9 - General technical specifications
• Ferguson hydraulic lifting system
  • 1 - Introduction
  • 2 - Ferguson hydraulic system operation
  • 3 - Ferguson hydraulic pump
  • 4 - Hydraulic lift cover
  • 5 - Outer hydraulic cylinders - MF 460 to 475
  • 6 - System final assembly
• Power take-off
  • 1 - Introduction
  • 2 - Removing the IPTO assembly
  • 3 - IPTO side cover and control valves assy
  • 4 - Pressure maintaining valve
  • 5 - Clutch disc pack assy
  • 6 - IPTO drive pump
  • 7 - Dual rotation PTO / IPTO - 1000 / 540 rpm
  • 8 - Reinstalling the IPTO assy into the tractor
  • 9 - Power take-off - PTO
• Electrical System
  • 1 - Presentation
  • 2 - Electrical board: fuses, relays, and diodes
  • 3 - Prestolite Alternator
  • 4 - Prestolite starter motor
  • 5 - Instrument panel
  • 6 - Miscellaneous components
• Auxiliary Hydraulic System
  • 1 - Introduction
  • 2 - Hydraulic testing
  • 3 - Danfoss hydrostatic unit
  • 4 - Danfoss prioritary valve - tractors MF 465 and 475
  • 5 - Auxiliary hydraulic control valve
  • 6 - Hydraulic pump(s)
  • 7 - Oil filtering
  • 8 - Heat exchanger (MF 465 and 475)
